plate rolling machine for shipbuilding industry
allen z
Contact person
Basic Information
W11-20*125001, main technical data: upper roller adding pressure: 490T Max width of roll board 12500mm The length of working rolls 12600mm Up roll diameter Φ380mm Down roll diameter Φ320mm Up Support roll diameter: Φ350mm Down support roll diameter: Φ270mm Distance between two down rolls 440mm Support rolls group: 7 No rolls of each group: 2 upper/ 4 down Drive speed about 3.5m/min Upper roll move speed while add pressure: 150mm/min Max capacity of coiled board : T20*B125008R500(σs≤345Mpa) Max stroke of upper roll: 410mm Hydraulic system working pressure: 19.5MPa Hydraulic motor 22KW Main motor 55KW Power:
Delivery terms and packaging
Packaging Detail: steel pallet.. Delivery Detail: 90days
